型号Model |
YLB500 |
YLB1000 |
|||
理论产置 (t/h) Theoretical Output |
40 |
80 |
|||
搅拌能力(kg/批次)Mixing Capacity |
500 |
1000 |
|||
燃料种类 Fuel |
标配:柴油、重油 (可选:天然气、煤等) Standard Configuration: Diesel、Heavy Oil(Optional:Natural Gas、Coal、etc.) |
||||
燃油消耗率(kg/t) Fuel Consumption |
≤6.5 |
||||
除尘类型 Dust Collector Type |
惯性除尘器 + 布袋除尘器 Inertial Dust Collector + Backflush Bag Filter |
||||
粉尘排放浓度 (mg/Nm³) Dust Emission Concentration |
≤50 |
||||
环境噪音 (dB(A)) Ambient Noise |
≤85 |
||||
操作工位噪音 (dB(A)) Operation Position Noise |
≤70 |
||||
振动筛 Vibrating Sieve |
四层七段式 4-Layer 7-Stage |
||||
提升机 Hoist |
板式链条Plate Chan |
||||
操作系统 Operating System |
手动/半自动/全自动 Manual/Semi-Automate/Fully Automatic |
||||
计量精度 Weighing Accuracy |
骨科 Aggregate |
动态 Dynamic |
≤±2.5% |
静态 Static |
≤±0.4% |
粉料 Powder |
≤±2.5% |
≤±0.3% |
|||
沥青 Asphalt |
≤±2.5% |
≤0.2% |
|||
移动单元数量(套)Number of Mobile Units |
1 |
5 |
|||
拖挂时速 (km/h)Trailer Speed |
≤40 |
||||
整机占地面积(长m*宽m)Area for Whole Plate |
41*22 |
33*25 |
|||
装机总功率(KW)Total Installed Power |
180 |
260 |
